Feat: All-in-one design, easy to carry.
Use: It is suitable for occasions that need to be stretched and closed.
| Specification | Capacity （T） | Working pressure (MPa) | Body Height (mm) | Stroke (mm) | Max force (kN) | Oil volume (cm²) | Extended height （mm） | Outer diameter (mm) | Plunger diameter (mm) | Weight (kg) |
KET-HPS-104 |
10 |
70 |
876 |
100 |
102 |
265 |
876 |
72 |
32 |
17 |
KET-HPS-204 |
20 |
70 |
1022 |
100 |
207 |
795 |
1122 |
95 |
41 |
32 |
