Feat: Safety break-off preventing device, the piston automatically returns to position.
Use: For bolt and nut installation and disassembly, the compact design is used in working conditions where the axial space is not restricted but the perimeter is limited.
Description：
● The compact design is used in working conditions of axial space unlimited, but both sides are limited;
● The min. upper thread projecting amount(h2) should be 1.0x bolt diameter D (according to the required pre-tightening force);
● Maximum working pressure 1800Bar/2250Bar;
● Used for hex nuts, heavy nuts, ISO4032, DIN 2510, EN14399 round nuts, round nuts and SV round nuts.
Product Features：
● Safety blowout prevention device;
● The piston self-return;
● Replace accessories according to the different thread and nut specifications.
● Optional measuring device of bolt tensioning amount;
● Gear direct-drive nut;
● Rotary sleeve with spring
● Over stroke limit;
● Operating hole;
● Safety handle;
● Counter.
Optional Products：
● Chromium nickel surface coating
● Safety measuring rod of thread projecting amount
● Portable safety cover
● Swivel high pressure male/female coupler
| Model | Pre-tightening Force | Thread d | Width across flats A/F | Diameter D3 | Altitude H1 | |||||
| （kN） | （lbs） | （mm） | （"） | （mm） | （"） | （mm） | （"） | （mm） | （"） | |
| KET-MSK24-10.9 | 308.5 | 69354 | M24 | 36 | 57.0 | 2.24 | 190.5 | 7.50 | ||
| KET-MSK27-10.9 | 401.5 | 90261 | M27 | 1 | 41 | 63.5 | 2.50 | 199.6 | 7.86 | |
| KET-MSK30-10.9 | 485.5 | 109152 | M30 | 46 | 70.0 | 2.76 | 202.7 | 7.98 | ||
| KET-MSK33-10.9 | 606.3 | 136302 | M33 | 1 ¼ | 50 | 2 | 78.3 | 3.08 | 224.6 | 8.84 |
| KET-MSK36-10.9 | 708.3 | 159233 | M36 | 55 | 82.6 | 3.25 | 237.0 | 9.33 | ||
| KET-MSK39-10.9 | 842.2 | 189335 | M39 | 1 ½ | 60 | 90.8 | 3.57 | 259.4 | 10.21 | |
| KET-MSK42-10.9 | 974.4 | 219044 | M42 | 65 | 98.0 | 3.86 | 263.0 | 10.35 | ||
| KET-MSK45-10.9 | 1140.5 | 256396 | M45 | 1 ¾ | 70 | 105.0 | 4.13 | 278.9 | 10.98 | |
| KET-MSK48-10.9 | 1288.4 | 289645 | M48 | 75 | 3 | 111.5 | 4.39 | 293.8 | 11.57 | |
| KET-MSK52-10.9 | 1529.7 | 343899 | M52 | 2 | 80 | 122.0 | 4.80 | 307.2 | 12.09 | |
| KET-MSK56-10.9 | 1785.0 | 401286 | M56 | 85 | 3 ½ | 130.5 | 5.14 | 350.4 | 13.80 | |
| KET-MSK60-10.9 | 2125.8 | 477892 | M60 | 90 | 3 ¾ | 140.8 | 5.54 | 342.0 | 13.46 | |
| KET-MSK64-10.9 | 2336.8 | 525336 | M64 | 2 ½ | 95 | 147.8 | 5.82 | 352.4 | 13.87 | |
| KET-MSK68-10.9 | 2745.0 | 617103 | M68 | 2 ¾ | 100 | 4 ¼ | 159.8 | 6.29 | 377.4 | 14.86 |
| KET-MSK72-10.9 | 3041.0 | 683697 | M72 | 3 | 105 | 168.0 | 6.61 | 387.0 | 15.24 | |
