Feat: Meanwhile the synchronous pump provides the same flow of hydraulic oil to different hydraulic pipelines to drive the hydraulic jack.
Use: Rely on the precise flow output of each pump head to ensure the synchronization of multiple hydraulic jacks.
Flow synchronization is realized on the basis of synchronous pumps, using a single motor to drive a hydraulic pump with multiple outlets. At the same time, the synchronous pump provides the same flow of hydraulic oil to drive the hydraulic jacks for different hydraulic lines. Rely on the precise flow output of each pump head to ensure synchronization of multiple hydraulic jacks (hydraulic jacks of the same tonnage). The size of the load has little effect on synchronization. The biggest feature of this system is to control the equal flow of each output, so as to realize the synchronization requirements of all points.
Maximum working pressure: 70MPa
Valves work individually or synchronously, with advance/ hold/ retract function
Joystick (manual) or pendant (solenoid) control
Adjustable pressure relief valve per circuit
| Pump Model Advance / Hold / Retract |
Outlets | Oil Tank Capacity (L) |
Flow Rate （L/min） |
Motor 380V 50Hz Three-Phase (kW) |
Weigh (kg) |
|
| Manual Valve | Solenoid Valve | |||||
| KET-SFP213MW | 2 | 40 | 1.30 | 5.5 | 240 | |
| KET-SFP213S | 2 | 40 | 1.30 | 5.5 | 240 | |
| KET-SFP228MW | 2 | 150 | 2.80 | 7.5 | 488 | |
| KET-SFP228S | 2 | 150 | 2.80 | 7.5 | 488 | |
| KET-SFP242MW | 2 | 150 | 4.20 | 11 | 526 | |
| KET-SFP242S | 4 | 150 | 4.20 | 11 | 526 | |
| KET-SFP404MW | 4 | 40 | 0.45 | 5.5 | 240 | |
| KET-SFP404S | 4 | 40 | 0.45 | 5.5 | 240 | |
| KET-SFP409MW | 4 | 150 | 0.90 | 5.5 | 475 | |
| KET-SFP409S | 4 | 150 | 0.90 | 5.5 | 475 | |
| KET-SFP414MW | 4 | 150 | 1.40 | 5.5 | 488 | |
| KET-SFP414S | 4 | 150 | 1.40 | 5.5 | 488 | |
| KET-SFP421MW | 4 | 150 | 2.10 | 7.5 | 526 | |
| KET-SFP421S | 4 | 150 | 2.10 | 7.5 | 526 | |
| KET-SFP604MW | 6 | 40 | 0.45 | 5.5 | 240 | |
| KET-SFP604S | 6 | 40 | 0.45 | 5.5 | 240 | |
| KET-SFP805MW | 8 | 150 | 0.55 | 7.5 | 510 | |
| KET-SFP805S | 8 | 150 | 0.55 | 7.5 | 510 | |
